X-eye SF160 Series
Detail View →
| X-ray Tube | 160 kV / 3 mA |
|---|---|
| Min. Resolution | 6 µm |
| Table Size | Max : 600 mm (Ø) X 900L mm |
| AXIS | X, Y, Z, R, Tilt, Z-t, Z-d |
| Detector | 1 M Pixel FPD |
| CT Scan Method | Cone beam CT |
| Dimension | 2,260(W) x 1,800(D) x 2,000(H) mm / 3,500kg |
Inspection System for Die Casting, Automotive Components, Defense Components, Cultural Assets and Large Products
Appropriate for the inspection of medium•large size components and detection of surface structure and defects (inside voids and cracks etc).
Due to high-energy, high-power Micro-focus X-ray Open Tube, maintenance cost's significantly reduced and long-term use possible with only replacing consumables.
Customization is available with selecting main parts by customers depends on their needs for size and material.
- Non-destructive analysis system for the large-size components
- Various options for X-ray Tubes and Detectors
- High power X-ray tube option
Wheel Porosity
Power Steering Crack
Applications
