X-eye SF160 Series
Detail View →
| X-ray Tube | 160 kV / 1 mA |
|---|---|
| Min. Resolution | 6 µm |
| Table Size | Max : 300 mm (Ø) X 300L mm |
| AXIS | X, Y, Z, R, T |
| Detector | 1.6 M Pixel FPD |
| CT Scan Method | Cone beam CT |
| Dimension | 1,840(W) x 1,860(D) x 1,700(H)mm / 2,000kg |
Inspection System for Die Casting, Automotive Components, Defense Components, Cultural Assets and Large Products
Appropriate for medium•large size component inspection and detecting surface structure and defects(inside voids and cracks etc).
Due to high-energy, high-power Micro-focus X-ray Open Tube, maintenance cost's reduced significantly and enables long-term use with only replacing consumables.
Customization is available with selecting main parts by customers depends on their needs for size and material.
- Non-destructive analysis system for small & medium sized components
- High-resolution images with Open Tube
- Enable to get CT images in very sort time using continuous scan (5 min.)
Connector
Car Accelerator
Applications
